Blackmagic URSA Cine 17K 65 and EVF CINEURSAA17K65/EVF

Name: Blackmagic URSA Cine 17K 65 and EVF CINEURSAA17K65/EVF
SKU: CINEURSAA17K65/EVF
Price: 22314.00 GBP
Availability: InStock

£22,314.00£18,595.00 inc VAT

Free delivery: Special product order.

Please contact Shotwize for delivery details.

Guaranteed Safe Checkout

Blackmagic URSA Cine 17K 65 is a revolution in digital film with an extremely large format 17520 x 8040 65mm RGBW sensor with larger photo-sites for 16 stops of dynamic range. This revolutionary model also includes interchangeable lens mounts, a dedicated assist station with a second 5″ HDR LCD touchscreen and industry standard Lemo and Fischer connections. Blackmagic URSA Cine 17K 65 comes with a massive 8TB of removable high performance media storage built in and also includes high speed 10G Ethernet, WiFi for fast media upload and syncing to Blackmagic Cloud and URSA Cine EVF!

BlackmagicURSA Cine 17K 65

Extremely large format digital film camera with 65mm RGBW 51x24mm sensor up to 17520 x 8040 resolution and 16 stops. Shoot 17K for giant IMAX style screens and centre crop for cinema and television deliverables.

Cinematic Large Format Sensor

URSA Cine features a revolutionary new sensor designed for incredible quality images at all resolutions from 4K to a massive 17K! Building on the original 12K RGBW Super 35 sensor, the new large format design features larger photo-sites, delivering an astounding 16 stops of dynamic range! The unique RGBW architecture provides equal amounts of red, green and blue pixels for incredible color super sampling. This means it is optimized to deliver incredibly rich colors at all resolutions and provide the ultimate in image quality and flexibility. Now you can capture more detail with a wider dynamic range than ever! Plus, in sensor scaling means you can record at all resolutions without cropping!

Cinematic Large Format Sensor

A Camera BodyOptimized for High End Productions!

URSA Cine is designed to meet the demands of any high end production. The camera body is built with a robust magnesium alloy chassis and lightweight carbon fiber polycarbonate composite skin to help you move quickly on set. Soft touch backlit buttons make controls easy to see in all conditions. There’s a 5″ fold out touchscreen for reviewing shots and accessing camera settings, plus a dedicated assist station on the other side of the camera, with 5″ LCD and full camera controls! Standard Lemo and Fischer connectors let you control the camera remotely while providing power for lens motors and other accessories. You also get 12G‑SDI out, 10G Ethernet, USB-C, XLR audio and more!

Large Format Flexibility

The large format sensors provide the ultimate in flexibility for aspect ratios, lenses and delivery formats! The full sensor area of the 12K LF gives you a stunning 3:2 open gate image, while the 17K 65 model provides a cinematic 2.20:1 image. Both models let you use the large sensor area to shoot anamorphic and deliver in a range of aspect ratios with 1.3, 1.5, 1.6, 1.66, 1.8 and 2x de-squeeze factors. Plus, you can shoot in 4K, 8K or 12K using the entire sensor without cropping, retaining the full field of view of your lenses. The 12K LF model even has 9K Super 35 modes for full compatibility with classic cinema lenses. All this lets you create distinctive content in the highest quality!

Interchangeable Lens Mounts

Different projects require different lenses which is why URSA Cine features an interchangeable lens mount. You can quickly switch between PL, LPL, EF and Hasselblad mounts. That means you can work with PL or LPL cinema lenses, EF or large format Hasselblad photographic lenses, making URSA Cine compatible with the widest possible range of professional lenses. Imagine using modern high speed lenses for sharp, precise images on one shoot and then shooting a period drama with vintage photographic lenses next! Plus, each mount has contact pins to read lens metadata for monitoring and for use in post production. With URSA Cine, you have the freedom to choose the lens you need for any kind of work!

High ResolutionMonitoring and Camera Control

URSA Cine lets crews work faster on set with multiple monitoring options! The fold out monitor has a large 5″ HDR touchscreen on one side and an external color status LCD on the other. You can even rotate the screen and fold it back into the camera! On the right side of the camera, there’s a dedicated assist station with a second 5″ HDR touchscreen which allows crew to work around the camera without needing external monitors. Plus, with a 1500 nit display and removable sunshade, it’s always visible, even in bright sunlight. On screen overlays show status and record parameters, histogram, frame guides and more. There’s even a dedicated focus puller’s mode to help you get perfect focus!

Rugged IndustryStandard Connections

The wide range of industry standard connections on URSA Cine make it perfect for high end cinema production. The 7 pin Lemo and 3 pin Fischer connectors at the front provide record start/stop and 24V power so are ideal for on board accessories such as focus motors. Camera power is provided by a standard 24V 8 pin Lemo connection, plus there’s an additional 2 pin Lemo 12V connection at the rear for lower voltage accessories. All this means you can power accessories straight from the camera without messy external cabling! There are also two independent 12G-SDI outputs for monitoring on 2 different monitors with different overlays, plus 10G Ethernet for Blackmagic Cloud media syncing!

BlackmagicRAW FueledImage Capture

Blackmagic RAW is a revolutionary format designed to capture and preserve the quality of the sensor data from your camera. Blackmagic RAW files store camera metadata, lens data, white balance, digital slate information and custom LUTs to ensure consistency of image on set and through post production. Constant quality options lock the quality level, allowing compression to adapt, matching the detail of the scene. Constant bitrate encoding options are designed to give you the best possible images with predictable and consistent file size. URSA Cine records to the Blackmagic Media Module 8TB, allowing you to capture over 4 hours of Blackmagic RAW in 12K or a massive 20 hours in 4K!

Blackmagic URSA Cine 17K 65 + EVF

Watch the Video

Specification

Camera Features

Effective Sensor Size

50.81 mm x 23.32 mm (65mm Format)

Pixel Pitch

2.9 microns

Lens Mount

PL mount. Interchangeable with URSA Cine Mount LPL included.

Lens Control

Lens data from compatible PL or LPL lenses and control of some PL lenses. Lens control of compatible EF lenses.

Dynamic Range

16 Stops

Shooting Formats

17,520 x 8040 (17K 2.2:1 open gate)
16,128 x 8040 (17K 2:1)
15,360 x 8040 (17K 17:9)
14,304 x 8040 (17K 16:9)
17,520 x 7296 (17K 2.4:1)

12,288 x 8040 (12K 3:2)
12,288 x 6912 (12K 16:9)
12,288 x 6480 (12K 17:9)
12,288 x 5112 (12K 2.4:1)
9648 x 8040 (12K 6:5)

11,680 x 5360 (8K 2.2:1 open gate)
10,752 x 5360 (8K 2:1 full height)
8192 x 5360 (8K 3:2)
8192 x 4608 (8K 16:9)
8192 x 4320 (8K 17:9)
8192 x 3408 (8K 2.4:1)

5840 x 2680 (4K 2.2:1 open gate)
5376 x 2680 (4K 2:1 full height)
4096 x 2680 (4K 3:2)
4096 x 2304 (4K 16:9)
4096 x 2160 (4K 17:9)
4096 x 1704 (4K 2.4:1)

Frame Rates

Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported. Maximum sensor frame rate dependent on resolution selected.

High Speed Frame Rates

17K 2.2:1 open gate up to 60 fps

12K 2.4:1 up to 90fps

8K 2.2:1 open gate up to 100 fps

8K 2.4:1 up to 170 fps

Built in ND Filters

None

Focus

Focus button turns on peaking, auto focus available using compatible lenses.

Iris Control

Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses so no pixel is clipped in film mode. Scene average auto exposure in video mode.

Screens

2 x Monitoring Screens

1 x Camera Status Screen

1 x Electronic Viewfinder

Monitoring Screen Dimensions

5 inch.

Monitoring Screen Resolution

1920px x 1080px

Monitoring Screen Brightness

1500 nits.

Monitoring Screen Type

LCD capacitive touchscreen

EVF Display Resolution

Full 1920 x 1080.

6.22 Million dots

EVF Display Type

OLED

EVF Diopter Range

-5 to +5

Tally

Live Tally Indicator on LCD, and URSA Cine EVF.

Metadata Support

Automatically populated lens data from i/Technology with compatible PL, LPL lenses and electronic EF and Hasselblad HC lenses when using optional EF lens mount or HC lens mount. Automatic recording of camera settings and slate data such as project, scene number, take and special notes.

Controls

Touchscreen menus on 5 inch screen. Push buttons for other controls. 7 assignable shortcut keys plus 6 assignable viewfinder shortcut keys on URSA Cine EVF.

Timecode Clock

Highly accurate timecode clock. Less than 1 frame drift every 8 hours.

Connections

Total Video Outputs

SDI Rates

1.5G, 3G, 6G, 12G.

Analog Audio Inputs

2 x XLR analog switchable between mic, line and AES audio. Phantom power support.

Analog Audio Outputs

1 x 3.5mm headphone jack

Reference Inputs

Tri-Sync/Black Burst and Timecode.

Viewfinder

1 x Viewfinder USB-C with video, power, camera control data and locking connector. Works with URSA Cine EVF and PYXIS Monitor.

USB-C Monitor Outputs

2 x USB-C side monitor ports support URSA Cine EVF, PYXIS Monitor or DisplayPort monitors.

URSA Cine EVF

1 x USB-C with power, data, video and locking connector.

Accessories

1 x 7-pin Lemo ‘EXT’ for power out, serial communication, and run/stop.

1 x 3-pin Fischer ‘RS’ for power out and run/stop.

Computer Interface

2 x USB-C side expansion ports for camera accessories.

Software updates using side USB-C closer to rear.

Ethernet

1 x 10Gb/s RJ‑45 connector supporting 10/100/1000/10G BASE-T for SMB file sharing, Web Media Management, Blackmagic Cloud uploads, camera control and streaming.

Blackmagic URSA Cine 17K 65 + EVF

Audio

Microphone

Integrated stereo microphone.

Built in Speaker

1 x mono speaker.

Standards

SD Video Standards

None

HD Video Standards

1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60

Ultra HD Video Standards

2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60

SDI Compliance

SMPTE 292M, SMPTE 424 Level B, SMPTE 2081-1, SMPTE 2082-1

SDI Audio Sampling

48 kHz and 24 bit

Media

1 x Blackmagic Media Module.

Media Format

Blackmagic

Supported Codecs

Codecs

Blackmagic RAW Constant Bitrate 3:1
Blackmagic RAW Constant Bitrate 5:1
Blackmagic RAW Constant Bitrate 8:1
Blackmagic RAW Constant Bitrate 12:1
Blackmagic RAW Constant Bitrate 18:1
Blackmagic RAW Constant Quality Q0
Blackmagic RAW Constant Quality Q1
Blackmagic RAW Constant Quality Q3
Blackmagic RAW Constant Quality Q5

H.264 Proxy in 1920 x 1080, 8-bit 4:2:0

Control

External Control

Blackmagic URSA Cine EVF can trigger record plus camera functions assigned to the VF1, VF2, VF3, Zoom, Exp and Record buttons. External Camera Control supported using REST API over Ethernet, WiFi or serial communication via the 7-pin Lemo connector. Run / Stop supported via 3-pin Fischer and 7-pin Lemo connector. Blackmagic iPad control and Bluetooth control supported. Blackmagic Zoom Demand and Blackmagic Focus Demand for controlling camera and compatible lenses.

Cloud Synchronization

Learn More

Streaming

Direct Streaming

Supports Secure Reliable Transport (SRT) and Real Time Messaging Protocol (RTMP) local live streaming using a Ethernet or WiFi, or global live streaming using an internet connection via Ethernet, WiFi or USB‑C cellular data.

Network Management

NTP

Network time protocol support allows you to sync the time on your camera, whenever connected to a network with any NTP server of your choice.

FTP

Download files from any drive attached to your camera using FTP.

Web Media Manager

Using a browser connected over Ethernet, web media manager allows you to access, browse, download and delete files from any drive connected to the camera.

SMB

File sharing using SMB

Storage Features

Storage Type

1 x Blackmagic Media Module 8TB

Storage Rates

Storage rates based on 24 frames per second.

17K – 17,520 x 8,040

Blackmagic RAW 3:1 – 1,700 MB/s
Blackmagic RAW 8:1 – 638 MB/s
Blackmagic RAW 12:1 – 425 MB/s
Blackmagic RAW 18:1 – 284 MB/s
Blackmagic RAW Q0 – 567 to 2,040 MB/s
Blackmagic RAW Q1 – 464 to 1,134 MB/s
Blackmagic RAW Q3 – 255 to 638 MB/s
Blackmagic RAW Q5 – 170 to 510 MB/s

12K – 12,288 x 8040

Blackmagic RAW 3:1 – 1,194 MB/s
Blackmagic RAW 8:1 – 448 MB/s
Blackmagic RAW 12:1 – 299 MB/s
Blackmagic RAW 18:1 – 199 MB/s
Blackmagic RAW Q0 – 398 to 1,433 MB/s
Blackmagic RAW Q1 – 326 to 796 MB/s
Blackmagic RAW Q3 – 179 to 448 MB/s
Blackmagic RAW Q5 – 120 to 358 MB/s

8K – 8192 x 5360

Blackmagic RAW 3:1 – 533 MB/s
Blackmagic RAW 5:1 – 320 MB/s
Blackmagic RAW 8:1 – 200 MB/s
Blackmagic RAW 12:1 – 133 MB/s
Blackmagic RAW Q0 – 320 to 639 MB/s
Blackmagic RAW Q1 – 228 to 533 MB/s
Blackmagic RAW Q3 – 133 to 400 MB/s
Blackmagic RAW Q5 – 100 to 266 MB/s

4K – 4096 x 2680

Blackmagic RAW 3:1 – 135 MB/s
Blackmagic RAW 4:1 – 101 MB/s
Blackmagic RAW 5:1 – 81 MB/s
Blackmagic RAW 6:1 – 68 MB/s
Blackmagic RAW Q0 – 202 to 336 MB/s
Blackmagic RAW Q1 – 135 to 311 MB/s
Blackmagic RAW Q3 – 101 to 238 MB/s
Blackmagic RAW Q5 – 81 to 202 MB/s

Recording Formats

Blackmagic RAW 3:1, 8:1, 12:1, 18:1, Q0, Q1, Q3 and Q5 at full sensor width or height resolutions:

[17,520 x 8,040], [16,128 x 8,040], [15,360 x 8,040], [14,304 x 8,040] and [17,520 x 7,296]

with film, extended video or video dynamic range or custom 3D LUT embedded in metadata plus simultaneous recording of H.264 1920 x 1080 Proxies.

Blackmagic RAW 3:1, 8:1, 12:1, 18:1, Q0, Q1, Q3 and Q5 at full sensor width or height resolutions:

[12,288 x 8,040], [12,288 x 6,912], [12,288 x 6,480], [12,288 x 5,112] and [9,648 x 8,040]

with film, extended video or video dynamic range or custom 3D LUT embedded in metadata plus simultaneous recording of H.264 1920 x 1080 Proxies.

Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3 and Q5 at full sensor width or height scaled to:

[11,680 x 5,360], [10,752 x 5,360], [8,192 x 5,360], [8,192 x 4,608], [8,192 x 4,320], [8,192 x 3,408] and [6,432 x 5,360]

with film, extended video or video dynamic range or custom 3D LUT embedded in metadata plus simultaneous recording of H.264 1920 x 1080 Proxies.

Blackmagic RAW 3:1, 4:1, 5:1, 6:1, Q0, Q1, Q3 and Q5 at full sensor width or height scaled to:

[5,840 x 2,680], [5,376 x 2,680], [4,096 x 2,680], [4,096 x 2,304], [4,096 x 2,160], [4,096 x 1,704] and [3,216 x 2,680]

with film, extended video or video dynamic range or custom 3D LUT embedded in metadata plus simultaneous recording of H.264 1920 x 1080 Proxies.

Constant Quality Rates for 17K and 12K are: Q0 9:1 – 2.5:1, Q1 11:1 – 4.5:1, Q3 20:1 – 8:1, Q5 30:1 – 10:1

Constant Quality Rates for 8K are: Q0 5:1 ‑ 2.5:1, Q1 7:1 ‑ 3:1, Q3 12:1 ‑ 4:1, Q5 16:1 ‑ 6:1

Constant Quality Rates for 4K are: Q0 2:1 ‑ 1.2:1, Q1 3:1 ‑ 1.3:1, Q3 4:1 ‑ 1.7:1, Q5 5:1 ‑ 2:1

Actual storage rates are dependent on image subject matter.

Software

Software Included

URSA Cine Blackmagic OS

DaVinci Resolve Studio for Mac and Windows including activation key

Blackmagic Camera Setup

Blackmagic RAW Player

Blackmagic RAW QuickLook Plugin

Blackmagic RAW SDK

Operating Systems

Mac 14.0 Sonoma,
Mac 15.0 Sequoia or later.

Windows 10 and 11.

Power Requirements

Power Supply

+24V DC external power supply 100 – 240 AC 50/60Hz compatible with IEC C14 socket.

B-Mount battery plate.

Power Input

1 x 8 pin Lemo compatible socket for external power or battery use.

Molex connector for rear battery plate.

Power Output

1 x 7-pin connector with +24V DC power output when camera is powered by +24V DC batteries or power supply.

1 x 3-pin Fischer with +24V DC power output when camera is powered by +24V DC batteries or power supply.

B-Mount battery plate including 2-pin connector with +12V regulated output from camera.

Accessories

Optional Accessories

Blackmagic URSA Cine EVF

Blackmagic PYXIS Monitor

Blackmagic PYXIS Monitor Kit

Blackmagic PYXIS Monitor EVF Kit

Blackmagic URSA Cine Mount PL

Blackmagic URSA Cine Mount EF (for limited shooting formats)

Blackmagic URSA Cine Mount HC

Blackmagic URSA Cine Mount Shims

Blackmagic URSA Cine Battery Plate B Mnt

Blackmagic URSA Cine Battery Plate Gold

Blackmagic URSA Cine Battery Plate VLock

Blackmagic URSA Cine Baseplate 15

Blackmagic URSA Cine Baseplate 19

Blackmagic URSA Cine Handle

Blackmagic URSA Cine Grips

Blackmagic URSA Cine 5″ LCD Sunshade

Blackmagic Media Dock

Blackmagic Media Module 8TB

ATEM Streaming Bridge

In the box

What’s Included

Blackmagic URSA Cine 17K 65 camera with PL lens mount

Blackmagic Media Module 8TB

Blackmagic Media Module Case

Blackmagic URSA Cine Handle and bolts

Blackmagic URSA Cine Top Rod Mount

Blackmagic URSA Cine Baseplate 19

Blackmagic URSA Cine Battery Plate B Mount

Blackmagic URSA Cine Rubber Caps for connectors

Blackmagic URSA Cine WiFi Antennas

Blackmagic URSA Cine Mount LPL and mount screws

Blackmagic URSA Cine 24V 250W power supply

Blackmagic PL Body Cap

Blackmagic LPL Body Cap

Plastic folding screen hood for 5” LCD

Blackmagic URSA Cine EVF

Blackmagic URSA Cine EVF Rotating bracket with 19mm carbon fibre rod

Blackmagic URSA Cine EVF Bracket rod mount

Blackmagic URSA Cine EVF Extension

2 short carbon fibre 15mm rods

1 x long USB viewfinder cable. Right angle to straight

1 x short USB viewfinder cable. Right angle to straight

1 x short USB viewfinder cable. Right angle to right angle

Rubber eyecup

Fabric eye chamois

DaVinci Resolve Studio with activation key

Welcome wallet with QR code for software download

Blackmagic Sticker

Blackmagic Design Sticker

Pelican 1560 Case with custom foam

Warranty

1 Year Limited Manufacturer’s Warranty.
